Agilent Technologies B1500A User Manual

4-46 Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3
Programming Examples for C++ Users
High Speed Spot C Measurement
Table 4-16 Open Correction Subprogram
void open_corr (ViSession vi, ViStatus ret, ViReal64 freq, ViReal64 ref_cp,
ViReal64 ref_g) /* 1 */
{
ViInt32 rbx;
ViInt16 result;
rbx = MessageBox(NULL , "Do you want to perform Open Correction?", "Open
Correction", MB_YESNO);
if (rbx != IDNO) {
MessageBox(NULL ,"Open measurement terminal. Then click OK.", "Open
Correction", MB_OK);
printf("Wait a minute . . .\n");
ret = agb1500_clearCorrData(vi, agb1500_CH_CMU, agb1500_CMUCORR_DEFAULT);
ret = agb1500_execOpenCorr(vi, agb1500_CH_CMU, freq, agb1500_CMUM_CP_G, ref_cp,
ref_g, &result);
if (result != 0) {check_err (vi, ret);}
ret = agb1500_setOpenCorrMode(vi, agb1500_CH_CMU, agb1500_FLAG_ON);
ret = agb1500_setShortCorrMode(vi, agb1500_CH_CMU, agb1500_FLAG_OFF);
ret = agb1500_setLoadCorrMode(vi, agb1500_CH_CMU, agb1500_FLAG_OFF);
if (result != 0) {check_err (vi, ret);} /* 15 */
}
}
Line Description
1 Beginning of the open_corr subprogram.
3 to 15 Displays a message box that asks if you perform the open correction. If you click Yes,
the open correction will be performed. It does not need a long time. The short correction
and the load correction are not performed in this example.
17 End of the open_corr subprogram.

Agilent Technologies B1500A Specifications

General

Type	Semiconductor Device Analyzer
Model	B1500A
Maximum Voltage	200 V
Number of SMUs	Up to 10
Frequency Range	DC to 1 MHz
Connectivity	USB, LAN
Channels	Up to 10
Interface	GUI

Summary

Installation

System Requirements

Details the necessary hardware and software for the driver.

Installing VXIplug&play Driver

Provides a step-by-step guide for installing the driver.

Before Programming

Covers pre-programming setup and configuration steps.

Driver Functions

Function List

Lists all available driver functions with brief descriptions.

Parameters

Details the parameters used by various driver functions.

Status Code

Describes the status codes returned by measurement functions.

Function Reference

Provides detailed descriptions and syntax for each driver function.

Visual Basic Programming Examples

Programming Basics

Basic information and steps for programming with the driver.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement using Visual Basic.

Staircase Sweep Measurement Example

Example for staircase sweep measurements.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage.

Leakage Current Measurement Example

Example for measuring leakage current.

C++ Programming Examples

Programming Basics

Basic information and steps for C++ programming.

High Speed Spot Measurement Example

Example demonstrating high-speed spot measurement in C++.

Staircase Sweep Measurement Example

Example for staircase sweep measurements in C++.

Breakdown Voltage Measurement Example

Example for measuring breakdown voltage in C++.

Leakage Current Measurement Example

Example for measuring leakage current in C++.

Sampling Measurement Example

Example for sampling measurement in C++.

CV Sweep Measurement Example

Example for CV sweep measurement in C++.
