Agilent B1500 VXIplug&play Driver Users Guide, Edition 3 2-11
Driver Functions
Table 2-5 SMU output current, resolution, and compliance by range
Output
range
(actually
used)
Setting
resolution
in A
Output
current
a
in A
a. Parameter name may be base, bias, peak, value, start, stop, and so on.
Maximum comp value
b
in V
b. This column shows the maximum value of the voltage compliance.
HPSMU MPSMU HRSMU
1 pA 1E-15 0 to ± 1.15 E-12 NA NA ±100
10 pA 5E-15 0 to ± 11.5 E-12 ±100
100 pA 5E-15 0 to ± 115 E-12 ±100
1 nA 50E-15 0 to ± 1.15 E-9 ±200 ±100 ±100
10 nA 500E-15 0 to ± 11.5 E-9 ±200 ±100 ±100
100 nA 5E-12 0 to ± 115 E-9 ±200 ±100 ±100
1 μA 50E-12 0 to ± 1.15E-6 ±200 ±100 ±100
10 μA 500E-12 0 to ± 11.5E-6 ±200 ±100 ±100
100 μA 5E-9 0 to ± 115E-6 ±200 ±100 ±100
1 mA 50E-9 0 to ± 1.15E-3 ±200 ±100 ±100
10 mA 500E-9 0 to ± 11.5E-3 ±200 ±100 ±100
100 mA 5E-6 0 to ± 20E-3 ±200 ±100 ±100
to ± 50E-3 ±200 ±40 ±40
to ± 100E-3 ±100 ±20 ±20
to ± 115E-3 ±100 NA NA
1 A 50E-6 0 to ± 50E-3 ±200
to ± 125E-3 ±100
to ± 500E-3 ±40
to ± 1 ±20
