Agilent B1500 VXIplug&play Driver User’s Guide, Edition 3 2-15
Driver Functions
Table 2-8 Status Values
Value Bit Description
0 - No error.
11
(LSB)
A/D converter overflowed.
2 2 One or more channels are oscillating. For SMU.
MFCMU is in the NULL loop unbalance condition.
4 3 Another channel reached its compliance setting. For SMU.
MFCMU is in the IV amplifier saturation condition.
8 4 This channel reached its compliance setting.
Normal post-measurement state by agb1500_measureBdv.
16 5 Target value was not found within the search range.
(for agb1500_readData)
Detection time was too long.
(for agb1500_measureBdv and agb1500_measureIleak)
32 6 Search measurement was automatically stopped.
(for agb1500_readData)
Output slew rate was too late.
(for agb1500_measureBdv and agb1500_measureIleak)
