Maintenance and Spare Parts
34 Cary Eclipse Fluorescence Spectrophotometer User’s Guide
6 Move the lamp module towards the front of the instrument to
disengage two guide pins at the rear.
7 Partially withdraw the module through the opening in the base.
8 Squeeze the clip on the plug (labeled ‘2’ in Figure 4) and remove
it from its socket
9 Completely withdraw the lamp module.
WARNING
Eye and Electrical Shock Hazards
When operating, the lamp module emits high intensity light which can
damage eyes. To avoid eye damage, never operate the lamp module outside
the instrument.
The lamp module contains components operating at high voltages. To avoid
electric shock, NEVER disassemble the lamp module.
To install the lamp module:
1 Plug the connector of the new lamp module into the socket in the
instrument.
2 Fit the lamp module in the base of the Cary Eclipse, ensuring that
the two guide pins are correctly located and that the wiring is
kept clear of the other parts of the instrument.
3 Tighten the three bolts through the front panel. Replace the lamp
access panel.
4 Replace the lamp module cover and tighten the four
thumbscrews.
5 Return the instrument to its upright position
6 Replace the power cable at the rear.
7 Turn on the computer and the instrument.
NOTE
After replacing the lamp module, you must align the lamp module.
