Agilent Technologies E5061B User Manual

Table 2-9 Performance Test failure Troubleshooting information (Option
115/117/135/137/215/217/235/237)
Test Num.
First failed test Probable faulty board
assembly or parts
A11 Source
Module
A3/A4
Receiver
Module
1 Frequency accuracy test ### #
2 RF output level accuracy test ### #
3 RF output level linearity test ### #
4 Crosstalk & system dynamic range
test
## ###
5 Noise Floor Test ## ###
6 Trace Noise Test # ###
7 Dynamic Accuracy Test
8 Compression ###
9 IF linearity at 1.195GHz ###
10 IF linearity at LF ###
11 Uncorrected System Performance
test
# ###
46 Chapter 2
Troubleshooting
Performance Test failure Troubleshooting
###: Most suspicious assembly
##: Suspicious assembly
#: Possible faulty assembly
