3-7
Replaceable Parts
Frequency, Hardware, and Personality Options
A21 Rear Panel Interface E8251-60203 3-16 and
3-12
E8251-60203 3-17 and
3-13
A22 Line Module 5064-5053 3-16 and
3-12
9135-5695 3-17 and
3-13
A23 Lowband Coupler/Detector E8251-60010 3-10, 3-16
and 3-14
E8251-60210 3-11, 3-17
and 3-15
A24 20 GHz Highband Coupler 0955-0148 3-10 and
3-14
0955-0148 3-11 and
3-15
A24 40 GHz Highband Coupler 0955-1136 3-10 and
3-14
N/A
A25 20 GHz Highband Detector 08360-60147 3-10 and
3-14
08360-60147 3-11 and
3-15
A25 40 GHz Highband Detector 08360-60148 3-10 and
3-14
N/A
A25B Highband Detector Bias Board 08360-60091 3-10 and
3-14
08360-60091 3-11 and
3-15
A26 MID (Microwave Interface Deck) E8251-60009 3-10 and
3-14
E8251-60069 3-11 and
3-15
A27 40 GHz Doubler (Option 540) 5087-7064 3-10 and
3-14
N/A
A27 40 GHz Doubler with High Power
(Option 540 and Option 1EA)
5087-7064 3-10 and
3-14
N/A
A28 YIG Oscillator 5087-7113 3-16 and
3-14
5087-7113 3-17 and
3-15
A29 20 GHz Doubler 5087-7058 3-16 and
3-14
5087-7058 3-17 and
3-15
A30 Modulation Filter with High
Power
5087-7061 3-16 and
3-14
5087-7061 3-17 and
3-15
A31 Motherboard E8251-60091 3-16 E8251-60201 3-17
A32 10 MHz Crystal Oscillator (Option
UNR)
E8251-60071 3-10 and
3-12
E8251-60071 3-11 and
3-13
A33 3.5 6dB PAD N/A 08493-60014 3-11 and
3-15
A34 Internal Hard Drive N/A E8251-60115 3-11 and
3-13
A35 3-20 GHz I/Q Modulator N/A 5087-7059 3-11
Assembly
E8247C
E8257C
E8267C
