3-45
Replaceable Parts
Frequency, Hardware, and Personality Options
Main Chassis with Inside Cover and Right-Side Support Wall
Figure 3-27 Main Chassis with Inside Cover and Right-Side Support Wall
Table 3-14 Main Chassis with Inside Cover and Right-Side Support Wall
Item No. Description Qty Part Number
1 Main Chassis Inside Top Cover 1 E8251-00011
2 Screw-Machine M3.0 x 08 FL-TX (inside top cover to main chassis and
rear panel)
9 0515-0430
3 Screw-Machine M3.0 x 08 CW-PN-TX (rear panel to right-side support
wall)
3 0515-0372
4 Screw-Machine M3.0 x 08 FL-TX (microcircuit interface deck to
right-side support wall)
6 0515-1035
5 Right-Side Support Wall 1
6 Microcircuit Interface Deck 1 E8251-00004
7 Main Chassis 1 E8251-60030
