Replaceable Parts
Frequency, Hardware, and Personality Options
Main Chassis and MID Bottom View
Table 3-10 Main Chassis and MID Bottom View
Item No. Description Qty Part Number
1 Rib Bracket 1 E8251-00008
2 Cable Retainer Clip
E8247C/57C
E8267C
3
4
E8251-40001
3 Screw-Machine M30. x 8 CW-PN-TX (A31 Motherboard to main chassis) 13 0515-0372
4 Screw-Machine M30. x 8 CW-PN-TX (A28 YIG Oscillator to MID) 2 0515-0372
5 Screw-Machine M30. x 20 CW-PN-TX (A30 Modulator Filter with
Standard or High Power to MID)
3 0515-1410
6 Screw-Machine M30. x 20 CW-PN-TX (A29 20 GHz Doubler to MID) 2 0515-1410
7 Screw-Machine M30. x 20 CW-PN-TX (A13 I/Q MUX to MID)
(E8267C)
3 0515-1410
