3-37

Replaceable Parts

Frequency, Hardware, and Personality Options

Microcircuit Interface Deck Top View

Figure 3-20 E8247C/57C Microcircuit Interface Deck Top View

Table 3-9 Microcircuit Interface Deck Top View

Item No. Description Qty Part Number

1 Screw-Machine M3.0 x 14 CW-PN-TX 1 0515-0665

Table of Contents3
Troubleshooting11
Electrostatic Discharge (ESD) Information12
Handling of Electronic Components and ESD12
Getting Started with Troubleshooting13
Running Self-Test13
A18 CPU Turn-On Test14
Failure Symptoms14
