6-66 Chapter6
Front-Panel Key Reference
Preset
NOTE If the Power On function is set to Preset and the Preset function is set to
Factory, turning on the analyzer performs a factory preset. Turning on
the analyzer also fetches alignment data; clears trace 2, trace 3, and
both the input and output buffers; turns off amplitude-correction
factors; turns off limit line testing; and sets the status byte to 0. The
last state of the analyzer (before it was turned off) is recalled if the
Power On key is set to Last (System, Power On/Preset, Power On). The
user preset state is recalled if the
Power On key is set to Preset and User
Preset is selected.
Table 6-1 Factory Preset Conditions
Amplitude correction factors off
Amplitude Ref off
Amplitude units default values
Annotation and graticule display on
Attenuation 10 dB (auto-coupled)
Center frequency:
E4401B and E4411B
E4402B and E4403B
E4404B
E4405B
E4407B and E4408B
750 MHz
1.5 GHz
3.35 GHz
6.6 GHz
13.25 GHz
CF step size 10% of span
Coupled functions all set to AUTO
Detector Peak
Display line level –25 dBm, display off
Frequency offset 0 Hz
Input Coupling AC
Int Preamp off
Limit line testing off
Log scale 10 dB/division
Marker count off
Marker counter resolution auto-coupled
Markers off
Max Mixer level –10 dBm
