Sweep
NOTE By selecting a number of sweep points greater than 401, you are
optimizing frequency resolution and accuracy while accepting a reduced
measurement speed. In addition to sweep points, the span, resolution
bandwidth, video bandwidth, and center frequency will also affect
measurement speed.
This function is not available when signal identification is on
(Input/Output, Input Mixer, Signal Ident (On)).
When zone span is on (Span, Zone. Zone (On)), each window has its own
value for points.
This feature is not available in the E4403B, E4408B, or E4411B (ESA-L
Series). The number of points per sweep for these models is always set
to 401.
Segmented Accesses the segmented sweep function and its editor.
Segmented sweep is a method in which you can select multiple
frequency bands (a maximum of 32), specify their parameters
individually, and display them as a single trace. This function of the
analyzer results in faster measurements and provides greater detail
and resolution in particular bands of interest. To set the parameters of
individual segments, go to the editor (
Sweep, Segmented, Modify, Edit)
and refer to the parameter key descriptions below. For measurement
examples of the segmented sweep function, refer to the Agilent
Technologies ESA Spectrum Analyzers Measurement Guide.
NOTE This feature is only available on ESA-E series analyzers (E4401B,
E4402B, E4404B, E4405B, E4407B) with firmware revision ≥ A.05.00.
Displaying the Trace
Turning segmented sweep on (
Sweep, Segmented, Segmented (On)),
displays each sweep segment from left to right in order of increasing
start frequency. When segments have the same start frequency, the
segments are displayed in order of increasing stop frequency.
Overlapping segments are acceptable. (The reference marker for a
marker delta will be displayed in the first segment).
Segments are demarcated by vertical lines. The width of a given
segment is determined by the ratio of the number of sweep points in the
segment to the number of sweep points in the total trace. For example,
if there are five segments with 101 sweep points each (505 total points),
each segment occupies 20% of trace. If you increase the number of
points in one of the segments to 404 (808 total points), that segment
will occupy half of the trace; the other four segments, 12.5% each. You
can define up to 32 segments with a total maximum number of sweep
points equal to 8192.
