Chapter 6 6-97
Front-Panel Key Reference
System (Local)
Licensing Accesses the security system to enable licensing for individual options.
For information on how to use this system, see the installation
information for individual options in the measurement personalities’
user’s guides.
NOTE Not all options can be enabled using this system and there is no way to
turn off an option through this system. Once an option has been
licensed for a given analyzer, it cannot be transferred to a different
analyzer.
Key Access:
System, More 1 of 3, More 2 of 3
Option Accesses the Alpha Editor allowing you to enter a three
character option number. To terminate the entry, press
Enter or Return. An external keyboard may also be used
for this entry. The option number will appear on the
second line of the
Option key. Key Access: System, More
1 of 3, More 2 of 3, Licensing
License Key Accesses the Alpha Editor allowing you to enter the
license key number. To terminate the entry, press
Enter
or Return. An external keyboard may also be used for
this entry. The license key number will appear on the
second line of the
License Key menu key.
Key Access:
System, More 1 of 3, More 2 of 3, Licensing
Date Format MDY
Time Date Display On
GPIB Address 18
Display Viewing Angle 4
Speaker Volume 0
Manual Tracking Adjustment 2048
External Amplifier Gain 0 dBm
Input Impedance
50 (Ohm)
a
a. This value maybe 75 ohms, depending upon the analyzer
hardware configuration.
Table 6-2 System Default Settings
Feature Default Setting
