FPD Ignitor and Heat Shield Assembly
Item Description Part No.
1 FPD Exit Tube Assembly
A
luminum 19256-60700
Stainless Steel 19256-20705
2 Ferrule, 1/4 in. Vespel, 10/pk 5080-8774
3 Emission chamber, single
FPD single 19256-80560
FPD, dual 19256-80600
4 FPD igniter replacement kit
Includes items A, B, C
19256-60800
A. O-ring, size 2-010
B. Spacer, ignitor
C. Glow plug
5 Igniter cable assembly G1535-60600
6 Heat shield gasket, white 19256-80045
7 First heat shield window 19256-80030
8 Heat shield disk 19256-20580
9 Stainless steel coupling 19256-20550
10 Lock washer (4 required) 2190-0584
11 Screw, M3 x 12, T10 (4 required) 0515-1084
12 Collar 19256-20690
13 Screw, M3 x 66 mm, T10 0515-0680
FPD ignitor and heat shield assembly
Tips & Tools
Track detector output. When it
increases by 50%, remove the
column, bake it out, replace the
igniter, or rebuild the detector.
