Detectors
TCD Filament Block Assemblies
Instrument Passivated Applications Specifications EPC Design Part No.
7890A Yes Standard TCD Analysis
Gases/Hydrocarbons
Filament Block Only
Must reuse heater/sensor
Original G3432-67685
6890 No Standard TCD Analysis
Gases/Hydrocarbons
Filament Block Only
Must reuse heater/sensor
Original G1532-60675
6890 No Standard TCD Analysis
Gases/Hydrocarbons
Filament Block Only
Must reuse heater/sensor
Minifold G1532-60685
6890 Yes Recommended for Fatty
Acid Analysis
Filament Block Only
Must reuse heater/sensor
Original G1532-60690
6890/6850 Yes Recommended for Fatty
Acid Analysis
Filament Block Only
Must reuse heater/sensor
Minifold G1532-60695
6890/6850 No Complete Detector Assembly
Includes detector palette
and heater/sensor assembly
Minifold G2630-61230
Determining the TCD Electronic Pressure Control (EPC)
If you have a 6890A or 6890A Plus GC, you may have an older design EPC Flow manifold
for the TCD. The older design requires removal of sheet metal panels to attached the TCD
reference flow gas supply inside the GC. The new "Minifold" design allows TCD reference
gas to be connected directly to the back of the GC. Replacement TCD filament block
assemblies have different part numbers depending on the EPC design type.
Once you have determined the type of EPC module, decide whether to order a passivated
filament block assembly. The passivated assembly is recommended for fatty acid analysis
or reactive/acidic samples.
