Verification and Calibration Appendix B
Series N8700 User’s Guide 111
Test Record – Agilent N8737A [60V, 55A, 3.3kW]
Agilent N8737A
Description
Report No _______________ Date __________________
Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
0 mV
Vout − 60 mV
59.94 V
Vout − 120 mV
_____________
_____________
_____________
_____________
+ 150 mV
Vout + 60 mV
60.06 V
Vout + 120 mV
CV Load Effect − 14 mV _____________ + 14 mV
CV Source Effect
− 8 mV
_____________
+ 8 mV
CV Ripple and Noise
peak-to-peak
rms
N/A
N/A
_____________
_____________
60 mV
8 mV
Transient Response
Voltage @ 1 ms − 300 mV _____________ + 300 mV
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
0 mA
Iout − 165 mA
54.835 A
Iout − 220 mA
_____________
_____________
_____________
_____________
+ 330 mA
Iout + 165 mA
55.165 A
Iout + 220 mA
CC Load Effect − 16 mA _____________ + 16 mA
CC Source Effect − 7.5 mA _____________ + 7.5 mA
WARNING
Return the voltage and current settings to zero when verification is completed
Test Description N8737A Settings
Voltage Programming & Readback, Min Voltage ≤120 mV, 220 mA
Voltage Programming & Readback, High Voltage 60V, 220 mA
CV Load Effect, Source Effect, Ripple and Noise 60V, 55A
Transient Response
60V, from 5.5A to 49.5A
Current Programming & Readback, Min Current 220 mA, 60V
Current Programming & Readback, High Current 55A, 60V
CC Load Effect, Source Effect 55A, 60V
N8737A Load Requirements
Current shunt 0.01
W
100 A
Agilent N3300 Electronic load modules 6 – N3306A
Fixed Resistor for CV Ripple and Noise 1.1
W
3.5 kW
