Agilent Technologies N8700 User Manual

Specifications Appendix A
Series N8700 User’s Guide 93
Supplemental Characteristics
Agilent Models N8731A – N8742A and Models N8754A – N8762A
Model 3.3kW
5kW
N8731A N8732A N8733A N8734A
N8754A
N8735A
N8755A
N8736A
N8756A
N8737A
N8757A
N8738A
N8758A
N8739A
N8759A
N8740A
N8760A
N8741A
N8761A
N8742A
N8762A
Output Response Time: (to settle to within ±1.0% of the rated output, with a resistive load)
Up, full load 3.3kW
0.08s
0.08s
0.08s
0.08s
0.08s
0.08s
0.15s
0.15s
0.15s
0.15s
0.15s
0.25s
Up, full load 5kW
0.03s
0.03s
0.03s
0.05s
0.05s
0.05s
0.05s
0.05s
0.1s
Down, full load
3.3kW
0.02s
0.1s
0.1s
0.1s
0.16s
0.16s
0.16s
0.3s
0.3s
0.3s
0.3s
0.5s
Down, full load 5kW
0.05s
0.08s
0.08s
0.08s
0.1s
0.1s
0.1s
0.1s
0.2s
Down, no load 3.3kW
0.5s
0.6s
0.7s
0.8s
0.9s
1.0s
1.1s
1.2s
1.5s
2.0s
3.5s
4.0s
Down, no load 5kW
0.7s
0.8s
0.9s
1.0s
1.2s
1.5s
2.0s
2.5s
3.0s
Command Response Time: (add this to the output response time to obtain the total programming time)
100 ms
Remote Sense Compensation: (the load lead drop reduces the maximum available voltage at the load)
Volts/load lead
3.3kW
2V
2V
2V
2V
5V
5V
5V
5V
5V
5V
5V
5V
Volts/load lead 5kW
2V
5V
5V
5V
5V
5V
5V
5V
5V
Over-voltage Protection:
Range 3.3kW
0.5-10
0.5-12
1-18
1-24V
2-36V
2-44V
5-66V
5-88V
5-110V
5-165V
5-330V
5-660V
Range 5kW
1-24V
2-36V
2-44V
5-66V
5-88V
5-110V
5-165V
5-330V
5-660V
Output Ripple and Noise: (for 8V-15V models, from 2V to 100% of rated output; for all other models, from 10% to 100% of rated output;)
CC rms 3.3kW
1.3A
1.2A
880mA
660mA
300mA
200mA
100mA
80mA
70mA
60mA
20mA
10mA
CC rms 5kW
1.0A
460mA
300mA
150mA
120mA
100mA
90mA
30mA
15mA
Programming Resolution:
Measurement Resolution:
Voltage 3.3kW
0.96mV
1.2mV
1.8mV
2.4mV
3.6mV
4.8mV
7.2mV
9.6mV
12mV
18mV
36mV
72mV
Voltage 5kW
2.4mV
3.6mV
4.8mV
7.2mV
9.6mV
12mV
18mV
36mV
72mV
Current 3.3kW
48mA
39.6mA
26.4mA
19.8mA
13.2mA
10.2mA
6.6mA
5.0mA
4.0mA
2.6mA
1.3mA
0.66mA
Current 5kW
30mA
20.4mA
15mA
10.2mA
7.8mA
6.0mA
4.1mA
2.0mA
1.0mA
Front Panel Display Accuracy: (4 digits; +% of rated output voltage; \1 count)
Voltage 3.3kW
40mV
50mV
75mV
100mV
150mV
200mV
300mV
400mV
500mV
750mV
1.5 V
3.0 V
Voltage 5kW
100mV
150mV
200mV
300mV
400mV
500mV
750mV
1.5 V
3.0 V
Current 3.3kW
2.0A
1.65A
1.10A
825mA
550mA
425mA
275mA
210mA
165mA
110mA
55mA
27.5mA
Current 5kW
1.25A
850mA
625mA
425mA
325mA
250mA
170mA
85mA
42.5mA
Temperature Stability: (over 8 hours, after a 30 minute warm-up, with constant line, load, and temperature)
Voltage 3.3kW
4mV
5mV
7.5mV
10mV
15mV
20mV
30mV
40mV
50mV
75mV
150mV
300mV
Voltage 5kW
10mV
15mV
20mV
30mV
40mV
50mV
75mV
150mV
300mV
Current 3.3kW
200mA
165mA
110mA
82.5mA
55mA
42.5mA
27.5mA
21mA
16.5mA
11mA
5.5mA
2.8mA
Current 5kW
125mA
85mA
62.5mA
42.5mA
32.5mV
25mV
17mA
8.5mA
4.3mA
Temperature Coefficient: (after a 30 minute warm-up)
Voltage 3.3kW units
100 PPM/°C from rated output voltage
Voltage 5kW units
100 PPM/°C from rated output voltage
Current 3.3kW units
200 PPM/°C from rated output current
Current 5kW units
100 PPM/°C from rated output current
