Agilent Technologies N8700 User Manual

Appendix A Specifications
94 Series N8700 User’s Guide
Supplemental Characteristics (continued)
Model 3.3kW
5kW
N8731A N8732A N8733A N8734A
N8754A
N8735A
N8755A
N8736A
N8756A
N8737A
N8757A
N8738A
N8758A
N8739A
N8759A
N8740A
N8760A
N8741A
N8761A
N8742A
N8762A
Analog Programming and Monitoring:
Vout voltage
0 - 100%, 0-5V or 0-10V, user selectable, Accuracy & linearity = ± 0.5% of rated Vout
Iout voltage
0 - 100%, 0-5V or 0-10V, user selectable, Accuracy & linearity = ± 1% of rated Iout
Vout resistance
0 - 100%, 0-5kW or 0-10kW, user selectable, Accuracy & linearity = ± 1% of rated Vout
Iout resistance
0 - 100%, 0-5kW or 0-10kW, user selectable, Accuracy & linearity = ± 1.5% of rated Iout
Iout monitor
0-5V or 0-10V, user selectable, Accuracy = ± 1%
Vout monitor
0-5V or 0-10V, user selectable, Accuracy = ± 1%
On/Off control
Electrical voltage; 0-0.6V or 2-15V or dry contact, user selectable logic
PS OK signal
TTL high (4-5V) = OK; 0V = FAIL; 500W series resistance
CV/CC signal 3.3kW
CV = TTL high (4-5V) source current 10 mA; CC = TTL low (0-0.6V) sink current 10 mA
CV/CC signal 5kW
Open collector; CV mode: OFF, CC mode: ON, Maximum voltage = 30V; Maximum sink current = 10 mA
Enable/Disable
Dry contact. Open=Off, Short=On. Maximum voltage at terminal = 6V.
Series and Parallel Capability:
Parallel operation Up to 4 identical units can be connected in master/slave mode with single–wire current balancing
Series operation Up to 2 identical units can be connected using external protection diodes (see Output Terminal Isolation)
Savable states:
In volatile memory 16 (in memory locations 0-15)
Interface Capabilities:
GPIB
LXI Compliance
USB 2.0
10/100 LAN
SCPI - 1993, IEEE 488.2 compliant interface
Class C (only applies to units with the LXI label on the front panel)
Requires Agilent IO Library version M.01.01 and up, or 14.0 and up
Requires Agilent IO Library version L.01.01 and up, or 14.0 and up
Environmental Conditions:
Environment
Operating temp.
Storage temp.
Operating humidity
Storage humidity
Altitude
Built-in Web server
Indoor use, installation category II (AC input), pollution degree 2
0°C to 40°C @ 100% load
–20°C to 85°C
Up to 90% relative humidity (no condensation)
10% to 95% relative humidity (no condensation)
Up to 3000 meters.
Above 2000m, derate the output current by 2%/100m and derate the maximum ambient temperature by 1°C/100m.
Requires Internet Explorer 5+ or Netscape 6.2+
Output Terminal Isolation:
8V to 60V units No output terminal may be more than ± 60 VDC from any other terminal or chassis ground.
80V to 600V units
No Positive output terminal may be more than ± 600 VDC from any other terminal or chassis ground.
No Negative output terminal may be more than ± 400 VDC from any other terminal or chassis ground.
Acoustic Noise Declaration:
Statements provided to comply with requirements of the German Sound Emission Directive, from 18 January 1991:
Sound Pressure Lp <70 dB(A), * At Operator Position, * Normal Operation, * According to EN 27779 (Type Test).
Schalldruckpegel Lp <70 dB(A) * Am Arbeitsplatz, * Normaler Betrieb, * Nach EN 27779 (Typprüfung).
