Agilent Technologies N8700 User Manual

Appendix A Specifications
92 Series N8700 User’s Guide
Performance Specifications
Agilent Models N8731A – N8742A and Models N8754A – N8762A
Model 3.3kW
5kW
N8731A N8732A N8733A N8734A
N8754A
N8735A
N8755A
N8736A
N8756A
N8737A
N8757A
N8738A
N8758A
N8739A
N8759A
N8740A
N8760A
N8741A
N8761A
N8742A
N8762A
DC Output Ratings:
NOTE 1
Voltage 3.3kW
8V
10V
15V
20V
30V
40V
60V
80V
100V
150V
300V
600V
Voltage 5kW
20V
30V
40V
60V
80V
100V
150V
300V
600V
Current 3.3kW
400A
330A
220A
165A
110A
85A
55A
42A
33A
22A
11A
5.5A
Current 5kW
250A
170A
125A
85A
65A
50A
34A
17A
8.5A
Power 3.3kW
3.2kW
3.3kW
3.3kW
3.3kW
3.3kW
3.4kW
3.3kW
3.36kW
3.3kW
3.3kW
3.3kW
3.3kW
Power 5kW
5kW
5.1kW
5kW
5.1kW
5.2kW
5kW
5.1kW
5.1kW
5.1kW
Output Ripple and Noise:
CV p-p
NOTE 2
3.3kW
60mV
60mV
60mV
60mV
60mV
60mV
60mV
80mV
100mV
100mV
300mV
500mV
CV p-p
NOTE 2
5kW
75mV
75mV
75mV
75mV
100mV
100mV
120mV
300mV
500mV
CV rms
NOTE 3
3.3kW
8mV
8mV
8mV
8mV
8mV
8mV
8mV
25mV
25mV
25mV
100mV
120mV
CV rms
NOTE 3
5kW
10mV
10mV
10mV
10mV
15mV
15mV
25mV
60mV
120mV
Load Effect: (change from 10% to 90% of full load)
Voltage 3.3kW
6.2mV
6.5mV
7.3mV
8mV
9.5mV
11mV
14mV
17mV
20mV
27.5mV
50mV
95mV
Voltage 5kW
8mV
9.5mV
11mV
14mV
17mV
20mV
27.5mV
50mV
95mV
Current 3.3kW
85mA
71mA
49mA
38mA
27mA
22mA
16mA
13.4mA 11.6mA
9.4mA
7.2mA
6.1mA
Current 5kW
250mA
170mA
125mA
85mA
65mA
50mA
34mA
17mA
8.5mA
Source Effect: (change from 170-265 Vac for 200 Vac models, or 342-460 Vac for 400 Vac models; with constant load)
Voltage 3.3kW
2.8mV
3mV
3.5mV
4mV
5mV
6mV
8mV
10mV
12mV
17mV
32mV
62mV
Voltage 5kW
2mV
3mV
4mV
6mV
8mV
10mV
15mV
30mV
60mV
Current 3.3kW
42mA
35mA
24mA
18.5mA
13mA
10.5mA
7.5mA
6.2mA
5.3mA
4.2mA
3.1mA
2.6mA
Current 5kW
125mA
85mA
62.5mA 42.5mA 32.5mA
25mA
17mA
8.5mA
4.3mA
Programming Accuracy:
NOTE 1
Voltage 3.3kW 0.05%+
4mV
5mV
7.5mV
10mV
15mV
20mV
30mV
40mV
50mV
75mV
150mV
300mV
Voltage 5kW 0.025%+
15mV
22.5mV
30mV
45mV
60mV
75mV
112.5mV
225mV
450mV
Current 3.3kW 0.1%+
800mA
660mA 440mA 330mA 220mA 170mA
110mA
84mA
66mA
44mA
22mA
11mA
Current 5kW 0.1%+
750mA 510mA 375mA 255mA 195mA 150mA 102mA
51mA
25.5mA
Measurement Accuracy:
Voltage 3.3kW 0.1%+
8mV
10mV
15mV
20mV
30mV
40mV
60mV
80mV
100mV
150mV
300mV
600mV
Voltage 5kW 0.025%+
25mV
37.5mV
50mV
75mV
100mV
125mV
187.5mV
375mV
750mV
Current 3.3kW 0.1%+
1.2A
990mA
660mA
495mA 330mA 255mA
165mA
126mA
99mA
66mA
33mA
16.5mA
Current 5kW 0.1%+
750mA
510mA
375mA
255mA
195mA
150mA
102mA
51mA
25.5mA
Load Transient Recovery Time:
(time for output voltage to recover within 0.5% of its rated output for a load change from 10% to 90% of its rated output current)
Time 3.3kW
≤ 1 ms
≤ 1 ms
≤ 1 ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 2ms
≤ 2ms
≤ 2ms
Time 5kW
≤ 1ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 1ms
≤ 2ms
≤ 2ms
≤ 2ms
Output set point
From 10% to 100% of rated output
NOTE 1
Minimum voltage is guaranteed to a maximum of 0.2% of the rated output voltage.
Minimum current is guaranteed to a maximum of 0.4% of the rated output current.
NOTE 2
20MHz
NOTE 3
From 5Hz - 1MHz
