Agilent Technologies N8700 User Manual

Quick Reference 1
Series N8700 User’s Guide 9
Programmable Functions
 Output voltage and current setting.
 Output voltage and current measurement.
 Output voltage and current trigger setting.
 Output On/Off control.
 Over-current protection setting.
 Over-voltage protection setting and readback.
 Under-voltage limit setting and readback.
 Start-up mode (either last setting or reset mode)
 Status register setting and readback.
 Bus trigger
 Calibration
Model Ratings
3.3 kW Models
Note 1, 2
5 kW Models
Note 1, 2
Model
Voltage
Range
Current
Range Model
Voltage
Range
Current
Range
N8731A 0 – 8V 0 – 400A N8754A 0 – 20V 0 – 250A
N8732A 0 – 10V 0 – 330A N8755A 0 – 30V 0 – 170A
N8733A 0 – 15V 0 – 220A N8756A 0 – 40V 0 – 125A
N8734A 0 – 20V 0 – 165A N8757A 0 – 60V 0 – 85A
N8735A 0 – 30V 0 – 110A N8758A 0 – 80V 0 – 65A
N8736A 0 – 40V 0 – 85A N8759A 0 – 100V 0 – 50A
N8737A 0 – 60V 0 – 55A N8760A 0 – 150V 0 – 34A
N8738A 0 – 80V 0 – 42A N8761A 0 – 300V 0 – 17A
N8739A 0 – 100V 0 – 33A N8762A 0 – 600V 0 – 8.5A
N8740A 0 – 150V 0 – 22A
N8741A 0 – 300V 0 – 11A
N8742A 0 – 600V 0 – 5.5A
Note 1: Minimum output voltage is ≤ 0.2% of the rated output voltage.
Note 2: Minimum output current is ≤ 0.4% of the rated output current.
