Series N8700 User’s Guide 91
Appendix A
Specifications
Performance Specifications ............................................................................ 92
Supplemental Characteristics ......................................................................... 93
Outline Diagram ................................................................................................. 96
This chapter lists the specifications and supplemental characteristics
of the Agilent N8700 power supplies. A dimensional line drawing of
the unit is included at the end of the chapter.
Unless otherwise noted, specifications are warranted over the
ambient temperature range of 0°to 40°C. Sensing is at the rear
terminals of the power supply after a 30-minute warm-up period.
Sense terminals are externally jumpered to their respective output
terminals.
Supplemental characteristics are not warranted but are descriptions
of typical performance determined either by design or type testing.
