Test Record – Agilent N8741A [300V, 11A, 3.3kW]
Agilent N8741A
Description
Report No _______________ Date __________________
Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
0 mV
Vout − 300 mV
299.7 V
Vout − 600 mV
_____________
_____________
_____________
_____________
+ 750 mV
Vout + 300 mV
300.3 V
Vout + 600 mV
CV Load Effect − 50 mV _____________ + 50 mV
CV Source Effect − 32 mV _____________ + 32 mV
CV Ripple and Noise
peak-to-peak
rms
N/A
N/A
_____________
_____________
300 mV
100 mV
Transient Response
Voltage @ 2 ms − 1.5V _____________ + 1.5V
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
0 mA
Iout − 33 mA
10.967 A
Iout − 44 mA
_____________
_____________
_____________
_____________
+ 66 mA
Iout + 33 mA
11.033 A
Iout + 44 mA
CC Load Effect − 7.2 mA _____________ + 7.2 mA
CC Source Effect − 3.1 mA _____________ + 3.1 mA
WARNING
Return the voltage and current settings to zero when verification is completed
Test Description N8741A Settings
Voltage Programming & Readback, Min Voltage ≤600 mV, 44 mA
Voltage Programming & Readback, High Voltage 300V, 44 mA
CV Load Effect, Source Effect, Ripple and Noise 300V, 11A
Transient Response 200V, from 1.1A to 9.9A
Current Programming & Readback, Min Current 44 mA, 300V
Current Programming & Readback, High Current 11A, 300V
CC Load Effect, Source Effect 11A, 300V
N8741A Load Requirements
Current shunt 0.1
W
15 A
Use fixed resistor instead of load modules
27.3
W
3.5 kW
(or Amrel 5KW 600V 300A electronic load)
Fixed Resistor for CV Ripple and Noise 27.3
W
3.5 kW
