Page #117 background imageLoading...
Page #117 background image
Verification and Calibration Appendix B
Series N8700 User’s Guide 117
Test Record Agilent N8754A [20V, 250A, 5kW]
Agilent N8754A
Description
Report No _______________ Date __________________
Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
0 mV
Vout − 25 mV
19.98 V
Vout − 30 mV
_____________
_____________
_____________
_____________
+ 55 mV
Vout + 25 mV
20.02 V
Vout + 30 mV
CV Load Effect − 8 mV _____________ + 8 mV
CV Source Effect − 2 mV _____________ + 2 mV
CV Ripple and Noise
peak-to-peak
rms
N/A
N/A
_____________
_____________
75 mV
10 mV
Transient Response
Voltage @ 1 ms
− 100 mV
_____________
+ 100 mV
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
0 mA
Iout − 750 mA
249 A
Iout − 1.0 A
_____________
_____________
_____________
_____________
+ 1.75 A
Iout + 750 mA
251 A
Iout + 1.0 A
CC Load Effect − 250 mA _____________ + 250 mA
CC Source Effect − 125 mA _____________ + 125 mA
WARNING
Return the voltage and current settings to zero when verification is completed
Test Description N8754A Settings
Voltage Programming & Readback, Min Voltage 30 mV, 1A
Voltage Programming & Readback, High Voltage 20V, 1A
CV Load Effect, Source Effect, Ripple and Noise 20V, 250A
Transient Response 20V, from 25A to 225A
Current Programming & Readback, Min Current 1A, 20V
Current Programming & Readback, High Current 250A, 20V
CC Load Effect, Source Effect 250A, 20V
N8754A Load Requirements
Current shunt 0.001
W
300 A
Agilent N3300 Electronic load modules 9 – N3306A
Fixed Resistor for CV Ripple and Noise 0.08
W
5.5 kW
