140 Series N8700 User’s Guide
RCL <reg> Recalls the saved settings. There are up to 16 store/recall states. Saved
settings must have been previously stored using the STO command.
*RCL
Queries the revision date of the power supply's firmware.
Resets any tripped protection.
SRQ <setting> Generates error 203. The service request capability of the power supply
is only supported using the SCPI commands
*SRQ
STO <reg> Stores the present power supply settings in the specified register. There
are up to 16 store/recall states.
*SAV
STS?
Note 1
Queries the present status. The response represents the sum of the
binary weights of the status register bits. The response is STS <n>
STAT:OPER:COND?
Causes the settings held with HOLD 1 to be executed.
UNMASK <setting>
Note 1
Sets the bits in the mask register to the setting. The setting is an integer
that represents the sum of the binary weights of the bits. The mask
register operates in conjunction with the status and fault registers.
STAT:OPER:NTR
STAT:OPER:PTR
STAT:QUES:NTR
UNMASK?
Note 1
Queries the present setting of the mask register. The response is
UNMASK <n>.
STAT:OPER:NTR?
STAT:OPER:PTR?
STAT:QUES:NTR?
VMAX Sets the soft programming limit for voltage. Attempting to program the
voltage above this setting will generate an error.
Queries the VMAX setting. The response is VMAX <n>.
Queries the measured output voltage. The response is a real number.
Queries the present voltage setting. The response is a real number.
Note 1: Compatibility status definitions and values are as follows
OT – overtemperature tripped
AC – AC line voltge overage.dropout
RI – remote inhibit tripped
