Instructions for Use 16
Turbo-V 81-M User Manual / 87-900-983-01 (E) 189/228
The available controllers are the following:
Rack controller 81-AG: 969-8988
Rack controller 81-AG RS232/485: 969-8989
Rack controller 81-AG Profibus: 969-8990
PCB 24 V: 969-9538
Navigator Controller 81AG 24 Vdc: 969-8995
Navigator Controller 81AG 100-240 Vac: 969-8996
The Turbo-V 81-M can be installed in any position. Fix the Turbo-V
81-M in a stable position connecting the inlet flange of the turbopump
to a fixed counter-flange capable of withstanding a torque of 250 Nm
around its axis.
For example the ISO 63 flange can be fixed using high strength steel
clamps (as Agilent model IC 63250 DCMZ).
The following table shows the necessary number of clamps and the
relevant fixing torque.
Tab. 1
FLANGE FIXING DEVICE N. FIXING TORQUE
ISO 63 M10 clamps 4 22 Nm
The turbopump with ConFlat inlet flange must be fixed to the
vacuum chamber by means of the appropriate Agilent hardware. See
the appendix "Technical Information" for a detailed description.
NOTE
The Turbo-V 81-M cannot be fixed by means of its base.
CAUTION!
The Turbo-V 81-M belongs to the second installation (or overvoltage) category as
per directive EN 61010-1. Connect the device to a mains line that satisfy the
above category.
For installation of optional accessories, see "Technical Information".
