Technical Information 17
Turbo-V 81-M User Manual / 87-900-983-01 (E) 209/228
Water Cooling Kit Installation
Two types of water cooling kits are available to be mounted when the
pump is used under heavy load conditions or when air cooling is
insufficient.
The two model part numbers are: 969-9823 (metallic model), and
969-9824 (plastic model).
Figure 22
The items of the plastic model kit must be assembled as shown in the following
figure
CAUTION!
Figure 23
