Technical Information 17
Turbo-V 81-M User Manual / 87-900-983-01 (E) 199/228
Compliance with: UNI EN 292-1
UNI EN 292-2
EN-CENELEC 55011
IEC 1000-4-2 (ex 801-2)
IEC 1000-4-3 (ex 801-3)
IEC 1000-4-4 (ex 801-4)
EN 61010-1 (IEC 1010-1)
EN 1012-2
Storage temperature -20 °C to +70 °C
Input 60 Vac, three phase,
1350 Hz (max)
50 W max
Lubricant permanent lubrication
Installation category II
Pollution degree 2
Storage temperature - 20 °C to + 70 °C
Weight kg (lbs): ISO 63: 1.99 (4.39)
KF 40: 1.96 (4.32)
CFF 4.5”: 2.96 (6.53)
CFF 2.75”: 2.77 (6.11)
* (According to standard DIN 28 428, the base pressure is that
measured in a leak-free test dome, 48 hours after the completion of
test dome bake-out, with a Turbopump fitted with a ConFlat flange
and using the recommended pre-vacuum pump)
NOTE
When the Turbo-V 81-M has been stored at a tem-perature less than 5°C, wait
until the system has reached the above mentioned temperature.
