3 Specifications and Characteristics

38 U2000 Series Operating and Service Guide

Specifications

Frequency and Power Ranges

Connector Type

Model Frequency Range Power Range

U2000A 10 MHz to 18.0 GHz

–60 dBm to +20 dBm

U2001A 10 MHz to 6.0 GHz

U2002A 50 MHz to 24 GHz

U2004A 9 kHz to 6.0 GHz

U2000H 10 MHz to 18 GHz

–50 dBm to +30 dBmU2001H 10 MHz to 6 GHz

U2002H 50 MHz to 24 GHz

U2000B 10 MHz to 18 GHz

–30 dBm to +44 dBm

U2001B 10 MHz to 6 GHz

Model Connector Type Impedance

U2000/1/4A N-Type (m) 50 Ω

U2002A 3.5 mm (m) 50 Ω

U2000/1H N-Type (m) 50 Ω

U2002H 3.5 mm (m) 50 Ω

U2000/1B N-Type (m) 50 Ω
