3 Specifications and Characteristics

62 U2000 Series Operating and Service Guide

Cal Factor Uncertainty

Frequency

U2000A

Typical CF Uncertainty (25 °C ±10 °C)

10 MHz to 30 MHz 1.8%

30 MHz to 2 GHz 1.6%

2 GHz to 14 GHz 2.0%

14 GHz to 16 GHz 2.2%

16 GHz to 18 GHz 2.2%

Frequency

U2001A

Typical CF Uncertainty (25 °C ±10 °C)

10 MHz to 30 MHz 1.8%

30 MHz to 2 GHz 1.6%

2 GHz to 6 GHz 2.0%

Frequency

U2002A

Typical CF Uncertainty (25 °C ±10 °C)

50 MHz to 2 GHz 2.0%

2 GHz to 14 GHz 2.5%

14 GHz to 16 GHz 2.7%

16 GHz to 18 GHz 2.7%

18 GHz to 24 GHz 3.0%
