Specifications and Characteristics 3
U2000 Series Operating and Service Guide 67
General Characteristics
Physical Characteristics
Net Weight
U2000/1/4A 0.262 kg
U2002A 0.226 kg
U2000/1B 0.762 kg
U2000/1H 0.324 kg
U2002H 0.274 kg
Dimensions (L x W x H)
U2000/1/4A 163.75 mm x 46.00 mm x 35.90 mm
U2002A 134.37 mm x 46.00 mm x 35.90 mm
U2000/1B 308.00 mm x 115.00 mm x 84.00 mm
U2000/1H 207.00 mm x 46.00 mm x 36.00 mm
U2002H 164.00 mm x 46.00 mm x 36.00 mm
Storage and Shipment
Environment
The sensor should be stored in a clean, dry
environment
Temperature –30 °C to +70 °C (non-operating)
Relative Humidity
Non-operating up to 90% at 65 °C
(non-condensing)
Altitude Non-operating up to 4,600 metres (15,000 feet)
USB Standard
USB Speed Hi-Speed 2.0
