Agilent Technologies U2000 Series

To Next Page

To Previous Page

3 Specifications and Characteristics

64 U2000 Series Operating and Service Guide

Frequency

U2001H

Typical CF Uncertainty (25 °C ±10 °C)

10 MHz to 6 GHz 2.0%

Frequency

U2002H

Typical CF Uncertainty (25 °C ±10 °C)

50 MHz to 8 GHz 2.5%

8 GHz to 12.4 GHz 2.5%

12.4 GHz to 18 GHz 2.7%

18 GHz to 24 GHz 3.0%
