6 Grassland Mower Hopper 5000 Edition 02.97
Figure A
1 Clutch control lever for wheel-drive
2 Clutch control lever for mowing drive
3 Speed control lever
4 Starter handle
5 Handlebar
6 Steering bar / handle to lift the machine
7 Knurled nut for handlebar attachment
8 Round and flat bolt for handlebar attachment
9 Mowing drive hood
10 Rocker arm with grass deflector
11 Knife driver with driving stone
12 Cutter bar
13 Knife guard
14 Drive-wheel
15 Linch pin
16 Engine
17 Engine panel (only on Comfort version)
18 Name plate (ID no.)
Figures B, C, D
Briggs & Stratton engine
1 Fuel tank cap
2 Starter handle
3 Cooling grille
4 Engine filler and drain plug with oil dip-stick
5 Air filter
6 Carburetor
7 Engine type/Type no.
8 Spark plug, spark plug connector
9 Guarded exhaust
10 PRIMER (CLASSIC 35 version only)
Designation of Parts
