CHAPTER 14
74 75
MXm
14 Technical specifications and drawings
n
Display resolution
n
Display pages
n
Backlight
n
Ambient Light sensor
n
Shift Lights
n
Alarm LEDs
n
CAN connections
n
Analog Inputs
n
Digital Inputs
n
Digital outputs
n
Integrated track database
n
Inertial platform
n
Wi-Fi connection
n
Integrated GPS
n
ECU connection
n
External power
n
Internal memory
n
Pushbuttons
n
Connectors
n
Body
n
Weight
n
Dimensions
n
Waterproof
n
Analysis software
268x128 pixel
Up to 8 freely configurable
7 configurable RGB colours
Yes
5 freely configurable RGB LEDs
2 freely configurable RGB LEDs
2
4 fully configurable max 1.000Hz each
2 speed inputs, coil RPM input
2 hight side
Yes
9 axis internal platform
Yes
10Hz GPS+Glonass
CAN, RS232, K-Line
12V
4Gb
Metallic
37 pins motorsport connector
+ 4 pins power connector
Glass fiber reinforced Nylon
330g
137x88,4x31,9 mm
IP65
Race studio analisys freely downloadable from
www.aim-sportline.com
