Appendix A:
Specifications
A
Formats
525i
625i
1080i 50/59.94/60 Hz
1080psf 23.98/24 Hz
720p 50/59.94/60 Hz
Video Inputs and Outputs
Dual SDI/HD-SDI, SMPTE 259/274/292/296
HD component YPbPr/RGB (RGB is output only), SMPTE-274
SD component/composite/YC (S-Video)
Video A/D, D/A
12 bits
2x oversampled (HD)
4x oversampled (SD)
Audio Inputs and Outputs
8 Channel Balanced, 25 pin D (Tascam pinout)
8 Channel AES (BNC)
8 Channel SDI/HD-SDI Embedded
Audio levels
+12dBu, +15dBu, +18dBu, +24dBu, (Full Scale Digital)
LAN
10/100 automatic configuration
Automatic cable crossover (auto MDI-X)
Embedded web server HTTP v1.1
SNMP
VTECS™ protocol for Remote Control Panel
