40
2.21 Audio Map Ch 1/2
This parameter is used with parameter 2.2—when Stereo Map is selected—to specify
the source of the channel pair for audio output channels 1 and 2. Possible choices (24
in all) are:
Note:
If parameter 4.5 Audio Follow Video is set to On, then Audio Map Ch1/2
selection is independently kept for each separate input: SDI 1, SDI 2, Composite,
S-Video, and Component. If Audio Follow Video is set to Off, then another Audio Map
Ch1/2 selection is used. This note applies to Parameters 2.21 through 2.24.
2.22 Audio Map Ch 3/4
This parameter is used with parameter 2.2—when Stereo Map is selected—to specify
the source of the channel pair for audio output channels 3 and 4. Possible choices are
the same as parameter 2.21. Default = AES Ch 3/4.
2.23 Audio Map Ch 5/6
This parameter is used with parameter 2.2—when Stereo Map is selected—to specify
the source of the channel pair for audio output channels 5 and 6. Possible choices are
the same as parameter 2.21. Default = AES Ch 5/6.
2.21 Audio Map Ch1/2 Description of Choices
Parameter Adjustments:
AES Ch 1/2 (default)
AES Ch 3/4
AES Ch 5/6
AES Ch 7/8
Analog Ch 1/2
Analog Ch 3/4
Analog Ch 5/6
Analog Ch 7/8
SDI 1 Ch 1/2
SDI 1 Ch 3/4
SDI 1 Ch 5/6
SDI 1 Ch 7/8
SDI 2 Ch 1/2
SDI 2 Ch 3/4
SDI 2 Ch 5/6
SDI 2 Ch 7/8
SDI 1 Ch 9/10
SDI 1 Ch 11/12
SDI 1 Ch 13/14
SDI 1 Ch 15/16
SDI 2 Ch 9/10
SDI 2 Ch 11/12
SDI 2 Ch 13/14
SDI 2 Ch 15/16
Mute
Selects AES Channels 1/2, and maps them to Channel 1/2 audio out.
Selects AES Channels 3/4, and maps them to Channel 1/2 audio out.
Selects AES Channels 5/6, and maps them to Channel 1/2 audio out.
Selects AES Channels 7/8, and maps them to Channel 1/2 audio out.
Selects Analog Channels 1/2, and maps them to Channel 1/2 audio out.
Selects Analog Channels 3/4, and maps them to Channel 1/2 audio out.
Selects Analog Channels 5/6, and maps them to Channel 1/2 audio out.
Selects Analog Channels 7/8, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 1/2, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 3/4, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 5/6, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 7/8, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 1/2, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 3/4, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 5/6, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 7/8, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 9/10, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 11/12, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 13/14, and maps them to Channel 1/2 audio out.
Selects SDI 1 Channels 15/16, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 9/10, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 11/12, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 13/14, and maps them to Channel 1/2 audio out.
Selects SDI 2 Channels 15/16, and maps them to Channel 1/2 audio out.
Mute Channel pair 1/2 (no audio)
