About Video and
Format
Compatibility
The table below shows at a glance all the conversions (and straight-through modes)
possible for given input formats. In the case of interlace formats the table lists the field
rate; for progressive formats the table lists the frame rate.
1
When the main output (SDI 1) is not 1080pSF23.98, bypass mode will not be
available.
Notes:
1. In the case of 1080pSF/23.98 input—and when 1080i59.94 (or 525) is selected as
an output format, the FS1 automatically adds 3:2 pulldown to get the correct frame
rate. Similarly, in the case of 1080pSF/24 input, FS1 automatically adds 3:2
pulldown to get the correct frame rate.
2. When passing 24 or 60 framerate video, the standard definition outputs will not
output valid video (the FS1 is not a framerate converter).
Input Possible Output Formats
525i59.94 525i59.94 720p59.94 1080i59.94
720p59.94 525i59.94 720p59.94 1080i59.94
1080i59.94 525i59.94 720p59.94 1080i59.94
1080pSF23.98 1080pSF23.98
1
1080i59.94 525i59.94
625i50 625i50 1080i50 720p50
720p50 625i50 1080i50 720p50
1080i50 625i50 1080i50 720p50
1080pSF24 1080pSF24 1080i60
1080i60 1080i60 720p60
720p60 720p60 1080i60
