106
RS422
DE-9: Reserved for future use.
GPI
DE-9: single connector provides two inputs and two outputs. See Appendix B for pinout and
specifications
Physical
Width: 17.25" (43.81cm)
Depth: 12.5" (31.75cm)
Height: 1RU, 1.75" (4.44cm)
Weight: 6.5lbs (2.94kg)
Operating temperature range: 0–40 degrees C
Convection cooled
Power
Voltage: 100-240 VAC
Power Consumption: 25W (30W maximum)
Two independent power supplies: fully redundant, diode isolated
