AJA FS1 - 4.5 Audio Follow Video

44
4.5 Audio Follow Video
This parameter determines whether audio settings are remembered for each video
input.
4.6 AFV Memory
Selecting this parameter and then pressing the up-arrow Adjust button saves the
current audio settings to source-memory for the currently selected video input.
Audio Follow Video applies to these
parameters:
Audio Follow Video does not
apply to these parameters:
• 2.2 Audio Input
• 2.11—2.18 Audio Map
• 2.21—2.24 Audio Map (Stereo)
• 4.2 Audio Delay
• 4.4 Sample Rate Convert
• 20.0 Audio Output Levels
• 20.1—20.8 Audio Level Ch (n)
• 21.0 Audio Output Phase
• 21.1—21.8 Audio Phase Ch (n)
Note: Turning Audio Follow Video (AFV) On
results in the loss of the above settings. When
AFV is turned On, the source-memory settings are
written over the current settings. Turning AFV Off
again will not restore the original settings, but
instead will result in the source memory settings
remaining in effect until edited again.
• 4.1 Analog Audio Std
• 4.3 Embed Audio Out
4.5 Audio Follow Video Description of Choices
Parameter Adjustments:
Off (Default)
On
Normal operation. Audio settings must be made separately from any video settings;
they are not associated automatically.
The FS1 remembers the saved audio settings associated with the currently
selected input. Whenever an input is selected, the corresponding audio settings will
be recalled.
This allows you to set up specific audio settings for the different video inputs (i.e.,
perhaps the SDI 1 has a specific embedded audio channel mapping while the
component video input might always use AES audio input).
