37.1 GPI 1 OUT
The setting of this parameter determines what (if any) FS1 event will generate a GPI
trigger output at GPI 1, pin 3 on DE-9.
37.2 GPI 2 OUT
The setting of this parameter determines what (if any) FS1 event will generate a GPI
trigger output at GPI 2, pin 4 on DE-9.
37.1 GPI 1 OUT Description of Choices
Parameter Adjustments:
No Action (Default)
Alarm
No Video
No Ref
Vid In SDI1
Vid In SDI2
Vid In Cmpst
Vid In S-Vid
Vid In Cmpnt
FS1 does not trigger a GPI 1 output trigger regardless of event.
FS1 generates a GPI 1 output trigger on pin 3 if an internal alarm condition occurs.
FS1 generates a GPI 1 output trigger on pin 3 if no video is detected at its selected
input.
FS1 generates a GPI 1 output trigger on pin 3 if no video is detected at its Ref
video input.
FS1 generates a GPI 1 output trigger on pin 3 if SDI1 is selected as the main video
input.
FS1 generates a GPI 1 output trigger on pin 3 if SDI2 is selected as the main video
input.
FS1 generates a GPI 1 output trigger on pin 3 if Composite is selected as the main
video input.
FS1 generates a GPI 1 output trigger on pin 3 if S-Video is selected as the main
video input.
FS1 generates a GPI 1 output trigger on pin 3 if Component is selected as the main
video input.
39.1 GPI 2 OUT Description of Choices
Parameter Adjustments:
No Action (Default)
Alarm
No Video
No Ref
Vid In SDI1
Vid In SDI2
Vid In Cmpst
Vid In S-Vid
Vid In Cmpnt
FS1 does not trigger a GPI 2 output trigger regardless of event.
FS1 generates a GPI 2 output trigger on pin 4 if an internal alarm condition occurs.
FS1 generates a GPI 2 output trigger on pin 4 if no video is detected at its selected
input.
FS1 generates a GPI 2 output trigger on pin 4 if no video is detected at its Ref
video input.
FS1 generates a GPI 2 output trigger on pin 4 if SDI1 is selected as the main video
input.
FS1 generates a GPI 2 output trigger on pin 4 if SDI2 is selected as the main video
input.
FS1 generates a GPI 2 output trigger on pin 4 if Composite is selected as the main
video input.
FS1 generates a GPI 2 output trigger on pin 4 if S-Video is selected as the main
video input.
FS1 generates a GPI 2 output trigger on pin 4 if Component is selected as the main
video input.
