FS1 Installation and Operation Manual — 2.12 Audio Map Ch2
Note: If parameter 4.5 Audio Follow Video is set to On, then Audio Map Ch1 selection
is independently kept for each separate input: SDI 1, SDI 2, Composite, S-Video, and
Component. If Audio Follow Video is set to Off, then another Audio Map Ch1 selection is
used. This note applies to Parameters 2.11 through 2.18.
2.12 Audio Map Ch2
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 2. Possible choices are the same as
parameter 2.11. Default = AES Ch 2.
2.13 Audio Map Ch3
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 3. Possible choices are the same as
parameter 2.11. Default = AES Ch 3.
2.14 Audio Map Ch4
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 4. Possible choices are the same as
parameter 2.11. Default = AES Ch 4.
2.15 Audio Map Ch5
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 5. Possible choices are the same as
parameter 2.11. Default = AES Ch 5.
2.16 Audio Map Ch6
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 6. Possible choices are the same as
parameter 2.11. Default = AES Ch 6.
2.17 Audio Map Ch7
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 7. Possible choices are the same as
parameter 2.11. Default = AES Ch 7.
2.18 Audio Map Ch8
This parameter is used with parameter 2.2—when Channel Map is selected—to specify
the source of the audio output on channel 8. Possible choices are the same as
parameter 2.11. Default = AES Ch 8.
