1
21
FS1 Installation and Operation Manual — Installation Overview
FS1 Network Example, Two FS1s on a LAN, with Laptop for Remote Control
10/100Base-T
Laptop
w/Web Browser
for FS1 Remote
Control
Firewall
& Router
WAN/ISP
Hub
10/100 Base-T
LAN
