FS1 Installation and Operation Manual — Remote FS1 Control Via a Web
Embed Audio Out (4.3)
Freeze Output (40.1)
SDI 2 Output (1.2)
Component Output (1.3)
Audio Follow Video (4.5)—This parameter determines whether audio settings are
remembered for each video input.
The Audio Follow Video control is also on the Audio Control screen.
On (default)
Off
Mute
Embedded audio will be passed.
Do not pass embedded audio packets to the SDI outputs.
FS1 outputs SDI embedded audio packets containing silence.
Off (default)
On
Normal operation. The FS1 outputs video from the input.
The FS1 captures and freezes the most current video frame and displays it on the outputs as
long as this parameter is set to On.
Normal (default)
Bypass
Standard Def
SDI 2 output follows the 1.1 Output Format parameter selection (both SDI 1 and SDI 2 are
the same)
SDI 2 output follows the format of the selected input
The output from Downconverter 2 (see block diagram in Chapter 1) is always standard
definition.
Normal (default)
Bypass
Standard Def
Component output follows the 1.1 Output Format parameter selection.
Component output follows the format of the selected input.
Note: Bypass mode does not work when the input is 1080pSF24 and output is 1080i60 (3:2)
pulldown mode.
Note 2: The signal type of the component output is defined in another selection, Component
Out, above in the screen (also parameter 3.2 from the parameter display)
The output from Downconverter 2 (see block diagram in Chapter 1) is always standard
definition.
Off (default)
On
Normal operation. Audio settings must be made separately from any video settings; they
are not associated automatically.
The FS1 remembers the audio settings associated with the currently selected input.
Whenever an input is selected, the corresponding audio settings will be recalled. This
allows you to set up specific audio settings for the different video inputs (i.e., perhaps
the SDI 1 input has a specific embedded audio channel mapping while the component
video input might always use AES audio input).
Audio Follow Video applies to these
parameters:
Audio Follow Video does not apply
to these parameters:
• 2.2 Audio Input
• 2.11—2.18 Audio Map
• 2.21—2.24 Audio Map (Stereo)
• 4.2 Audio Delay
• 4.4 Sample Rate Convert
• 20.0 Audio Output Levels
• 20.1—20.8 Audio Level Ch (n)
• 21.0 Audio Output Phase
• 21.1—21.8 Audio Phase Ch (n)
• 4.1 Analog Audio Std
• 4.3 Audio Out
