REFILLING FRONT BRAKE FUILD
― Remove the screws (1);
― Remove the reservoir cover (2) and the diaphragm (3);
― Place front brake reservoir in a horizontal position and fill up the reservoir until the
MIN mark with clean brake fluid DOT 4;
― Replace diaphragm, cover and screws if damaged;
― Clean the spilled or overflowed brake fluid with water.
Do not let brake fluid get in contact with paint. Brake fluid is highly corrosive and
may damage painted parts of the vehicle.
CHECKING REAR BRAKE FLUID LEVEL
The rear brake reservoir is integrated in brake master cylinder and is located on the right side
of the motorcycle, near of the swing arm.
Verify the brake fluid level in the level glass (4).
The oil level must be above the MIN mark when the motorcycle is in the upright
position.
