The taillight (1) is composed by a set of LEDS and does not allow replacing them. In case of
presence or stop light failure, the taillight must be replaced.
To replace the taillight:
― Disconnect the taillight wire connector near the battery;
― Remove the three screws of the number-plate holder;
― Remove the two taillight nuts;
― Replace the taillight with a new one.
REPLACING TURN INDICATOR LIGHTS
In order to replace front and rear turn indicator lights, turn the ignition key to OFF or LOCK
position.
― Release the screw (2);
― Remove the turn indicator lens (5) and the inner glass (4);
― Press down the lamp (3) rotate it counter-clockwise;
― Assembly the new turn indicator lamp;
― Clean the lamp with alcohol;
― Place the inner glass and the turn indicator lens;
― Tight again the screw.
The fully replacement of the turn indicator assembly should be performed by an authorized AJP
dealer.
