REFILLING REAR BRAKE FUILD
― Remove the master cylinder cover (1);
― Place rear brake master in a horizontal position and fill up the reservoir until the MIN
mark with clean brake fluid DOT 4;
― Replace diaphragm and reservoir cover if damaged;
― Clean the spilled or overflowed brake fluid with water.
Do not let brake fluid get in contact with paint. Brake fluid is highly corrosive and
may damage painted parts of the vehicle.
CHANGING REAR BRAKE PEDAL POSITION
The rear brake pedal position can be modified rotating the bolt (3).
Adjust the piston rod (2) to control the brake pedal free play. The rear brake pedal must have
1 to 2 mm of free play.
If there is no brake pedal free play, the pressure can build up in brake system
while driving and block the rear wheel. Brake system can overheat and even
completely fail in extreme cases.
Do not press continuously the rear brake pedal while riding.
