VI. ADJUSTMENTS
1. CLOCK FREQUENCY ADJUSTMENT (Refer to Fig. 3-10)
T2
0
TP2 QQ
1) Connect a Frequency Counter to TPI (TP2).
2) Confinn
that Frequency Counter reading is
400
kHz~ 430 kHz.
--c::>- C4 3
TP I !!IC:)- C44
~
Tl
Fig. 3-10 AA-R32/L, AA-R42 Control PCB
3) Adjust Tl (Frequency of TPl) or T2 {Frequency
of TP2), if adjustment is necessary.
------------SERVICE MANUAL AA·R32/L, AA•R42------------
56
