3. Place and hold a piece of cardboard over the PCB, then flip the cardboard and
PCB in one smooth motion.
4. The transistors will fall down, but their height above the board is nicely set by the
heights of components already installed on the board.
5. Make sure that the transistor leads are straight up and down, then solder all the
transistor leads.
Designation Value Description Done

Q1
2N3904
NPN transistor, T0
-
92 package
Q2
2N3904
NPN transistor, T0
-
92 package
Q3
2N3904
NPN transistor, T0
-
92 package
Q4
2N3904
NPN transistor, T0
-
92 package
Q5
2N3904
NPN transistor, T0
-
92 package
Q6
2N3904
NPN transistor, T0
-
92 package
Q7
2N3904
NPN transistor, T0
-
92 package
Q8
2N3904
NPN transistor, T0
-
92 package
Q9
2N3904
NPN transistor, T0
-
92 package
Q10
2N3904
NPN transistor, T0
-
92 package
Install the Tall Film Capacitors
Designation Value Description Done

C12
1 µF
Film capacitor, marked 1J63 on top
C13
1 µF
Film capacitor, marked 1J63 on top
C14
1 µF
Film capacitor, marked 1J63 on top
C15
1 µF
Film capacitor, marked 1J63 on
top
C16
1 µF
Film capacitor, marked 1J63 on top
C17
1 µF
Film capacitor, marked 1J63 on top
Install the electrolytic capacitor
Watch the polarity. Make sure that the side of the capacitor with the negative sign is
away from the silk screen with the positive sign.
Designation Value Description Done

C30
47 µF
Electrolytic, 50 V, watch the polarity!
Install J1 and J2
Align each connector carefully with the holes in the board. Squeeze the connector onto
the board. Keep your fingers outside of the hole pattern so you don’t jab yourself when
the pins pop through the board. It will take a little squeezing and wiggling, but it fits very
nicely and securely. It will make a popping sound as it pushes into the board.
