Akiyama TEMPUS - Technical Specifications

TEMPUS. User Manual
27
5.2. Technical specifications
1. GENERAL SECTION
PRODUCT
2 Channel Digital Mixer & MIDI Controller
POWER SOURCE
DC12V, 2.0A
POWER CONSUMPTION
24WATTS
DIMENSIONS
410mm (W) X 297mm (D) X 65 mm (H)
WEIGHT
3.22kg
2. INPUT/OUTPUT IMPEDANCE & SENSITIVITY: (EQ FLAT, MAXIMUM GAIN)
2-1.INPUT IMPEDANCE AND REFERENCE INPUT LEVEL:
LINE
47K OHM /-14dBV(200mV)
AUX
47K OHM /-14dBV(200mV)
PHONO
47K OHM /-50dBV(3.16mV)
MIC
10K OHM /-54dBV(1.99mV)
2-2.OUTPUT IMPEDANCE AND REFERENCE OUT LEVEL (EQ FLAT, MAXIMUM GAIN):
MASTER
1K OHM /0dBV (1V)± 2dB
BOOTH
1K OHM /0dBV (1V) ± 2dB
BALANCED
600 OHM /1dBV(1.123V) ± 2dB
PHONES (load=32ohm)
3.3 OHM /4.0dBV(1.60V) ± 2dB
3. FREQUENCY RESPONSE: (EQ FLAT, MAX GAIN, MASTER=0dBV)
LINE
20 - 20K Hz± 2dB
AUX
20 - 20K Hz± 2dB
PHONO
20 - 20K Hz± 2dB (RIAA)
MIC
20 - 20K Hz± 2dB
4. THD + N: (EQ FLAT, MAX GAIN, MASTER=0dBV, 20kHz LPF, A-WEIGHTED)
LINE
LESS THAN 0.02%@ 1KHz
AUX
LESS THAN 0.02%@ 1KHz
PHONO
LESS THAN 0.2%@ 1KHz
MIC
LESS THAN 0.2%@ 1KHz
5. MAXIMUM INPUT: (1KHz, EQ FLAT, GAIN AT 12 O,CLOCK, LOAD=100K OHM, 20kHz LPF, A-WEIGHTED)
LINE
MORE THAN +9.0dBV/ THD<1%
AUX
MORE THAN +9.0dBV/ THD<1%
PHONO
MORE THAN -27.0dBV/ THD<1%
MIC
MORE THAN -31.0dBV/ THD<1%
6. MAX OUTPUT: (EQ FLAT, MAX GAIN, THD=1%, 20kHz LPF, A-WEIGHTED)
MASTER UNBALANCED
MORE THAN +14.0dBV (5.02V) LOAD=100K OHM
MASTER BALANCED
MORE THAN +15.0dBV (5.63V) LOAD=600 OHM
BOOTH
MORE THAN +14.0dBV (5.02V) LOAD=100K OHM
PHONES
MORE THAN +4.0dBV (1.60V ) LOAD=32 OHM
7. LINE1/LINE2/AUX INPUT S/N RATIO: (MAX GAIN, EQ FLAT, 20KHz LPF, A-WEIGHTED, MASTER=0dBV)
MASTER UNBALANCED
MORE THAN 80dB
MASTER BALANCED
MORE THAN 80dB
BOOTH
MORE THAN 80dB
PHONES
MORE THAN 80dB
8. PHONOGRAPH INPUT S/N RATIO: (MAX GAIN,EQ FLAT,20KHz LPF,A-WEIGHTED, MASTER=0dBV)
MASTER UNBALANCED
MORE THAN 75dB
9. MIC1/MIC2 INPUT S/N RATIO: (MAX GAIN, EQ FLAT, 20KHz LPF, A-WEIGHTED, MASTER=0dBV)
MASTER UNBALANCED
MORE THAN 70dB
10. CROSSTALK: (MAX GAIN, EQ FLAT, 20KHz LPF, A-WEIGHTED,MASTER=0dBV OUTPUT)
LINE1/2
MORE THAN 75dB @1KHz BETWEEN L AND R CHANNEL
LINE1/2
MORE THAN 75dB @1KHz BETWEEN CHANNELS
AUX
MORE THAN 75dB @1KHz BETWEEN L AND R CHANNEL
AUX
MORE THAN 75dB @1KHz BETWEEN CHANNELS
11. FADER KILL: (REFERENCE INPUT LEVEL,EQ FLAT, MAXIMUM GAIN)
More than 80dB at 1K Hz for channel and cross faders.
12. TALKOVER:
-30dB ± 1dB
13. CHANNEL BALANCE:
Within 1dB
14. TONE, EQ:( Flat setting 0±2dB )
MIC:
-28± 1dB at 100Hz
-30± 1dB at 10kHz
15. EQUALIZER RESPONSE: ( Flat setting 0±2dB )
CHANNEL:
(1) Low Band: ( Low Band center frequency is 60Hz )
Maximum level:
+10 ± 1dB (at 60Hz)
Minimum level(Kill):
Less than -34dB (at 60Hz)
(2) Middle Band: ( Middle Band center frequency is 1KHz )
Maximum level:
+10 ± 1dB (at 1KHz)
Minimum level(Kill):
Less than -34dB (at 1KHz)
