8.2.3 Mod ICON
8.2.4 Auto Run Icon
Icon Auto run reason
Remote start input
Low battery run
Sheduled run
Mains failure
Icon Decription
Appears when the engine is at rest and the unit is in stop mode.
Appears when the engine is at rest and the unit is in auto mode.
Appears when the engine is a rest and the unit is in test mode.
Appears when the engine is at rest and the unit is in armed mode.
Appears when a timer is active, for example cranking time, crank rest etc.
Appears when the engine is running, and all timers have expired, either on or off load.
The animation speed is be reduced when running in idle mode.
Appears when the unit is in the front panel editor.
Appears when a USB connection is made to the controller.
Appears if either the configuration file or engine file becomes corrupted.
