63
FTP Path: Enter the folder name you created in FTP server.
4.4.3.3. Input Interface Triggered Action
Go to the path Intercom - Input on the website to configure.
Action Delay: To configure after how long to execute to send out
notifications and trigger relay.
Open Relay: To configure which relay to trigger.
4.5. Upgrade
4.5.1. Web Update
Login to the website and go to the path Upgrade - Basic, users
can upgrade firmware.
Upgrade: Choose .zip/.rom firmware from your PC, then click
Submit to start update.
Figure 4.4.3.3 Input interface triggered action
Figure 4.5.1 Web update

Table of Contents

Other manuals for Akuvox R29 Series

Preview: User Manual
User Manual16 pages
Preview: Administrator's Guide
Administrator's Guide187 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Akuvox R29 Series and is the answer not in the manual?

Akuvox R29 Series Specifications

General IconGeneral
PowerPoE or 12V DC
Operating SystemAndroid
RS485Yes
WiegandYes
InstallationWall-mounted
Tamper-proofYes
ProcessorQuad-Core
RAM2GB
Display7-Inch LCD
Camera2MP
NetworkEthernet
IntegrationSIP, ONVIF
Light compensationYes
Ethernet10/100M
PoE802.3af
Operating Humidity10% to 90% (non-condensing)
Storage8GB
ProtocolsSIP, ONVIF, RTSP
