PUMPS ALHS25 TO ALH125
Connections SHAFT
B C D H L M N
O ISO
FLANGES
R I DIAMETER
FRAME
FASTENINGS
ALHS25
262
(10.3)
356
(14.0)
134
(5.3)
110
(4.3)
192
(7.5)
62
(2.4)
62
(2.4)
ANSI 1 in / 150# (DN25 PN16)
110
(4.3)
63
(2.5)
30k6 4xM10
ALHS32
ALHS40
330
(13.0)
438
(17.2)
237
(9.3)
158
(6.2)
263
(10.3)
85
(3.3)
75
(2.9)
ANSI 1.25 in / 150# (DN32 PN16)
ANSI 1.5 in / 150# (DN40 PN16)
158
(6.2)
92
(3.6)
40k6 4xM12
ALHSX40
430
(16.9)
414
(16.3)
294
(11.6)
159.4
(6.3)
260
(10.2)
74
(2.9)
64
(2.5)
ANSI 1.5 in / 150# (DN40 PN16)
159.4
(6.3)
102.5
(4.0)
40k6 4xM12
ALHS50
ALHS65
554
(21.8)
522
(20.5)
360
(14.1)
257
(10.1)
325
(12.8)
99.5
(3.9)
87.6
(3.4)
ANSI 2 in / 150# (DN50 PN16)
ANSI 2.5 in / 150# (DN65 PN16)
186.5
(7.3)
104.5
(4.1)
50k6 4xM16
ALHSX65 N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A
ALHSX80
746
(29.3)
609
(24.0)
473
(18.6)
290
(11.4)
395.4
(15.6)
108
(4.2)
108
(4.2)
ANSI 3 in / 150# (DN80 PN16)
167
(6.6)
131.4
(5.2)
70k6 4xM20
ALHS80
876
(34.5)
803
(31.6)
561
(22.0)
345
(13.6)
387.4
(15.2)
125
(4.9)
108.5
(4.3)
ANSI 3 in / 150# (DN80 PN16)
345
(13.6)
131.4
(5.3)
80k6 4xM20
ALHS100
1040
(40.9)
911
(35.6)
698
(27.5)
387
(15.2)
530
(20.9)
147
(5.8)
131
(5.1)
ANSI 4 in / 150# (DN100 PN16)
387
(15.2)
153
(6.0)
100k6 4xM20
ALHS125
1273
(50.1)
1037
(40.8)
818
(32.2)
500
(19.7)
606
(23.8)
160.5
(6.3)
144.5
(5.7)
ANSI 5 in / 150# (DN125 PN16)
500
(19.7)
216
(8.5)
120k6 4xM24
ALH
Characteristics / Technical Specications
DIMENSIONS
mm (Inch)
